CNC Prototyping for Parts That Must Be Tested

What this page covers

• Prototype machining for single parts and first articles
• Prototype manufacturing that keeps the production process in view from the first part
• Metal and plastic prototype parts, including aluminium, steel, titanium, copper alloys and engineering plastics
• Surface finishing available on prototype parts where the test needs the real finish

What to confirm before ordering

A prototype answers a specific question: fit, function, material behaviour or assembly. Say which question your prototype must answer when you send the drawing, so the process and finish are chosen for that test. Before ordering, confirm minimum order quantity and lead time for your drawings.

Drawing checklist

Send the drawing with units and scale stated, the material and grade, the critical dimensions and tolerances marked, and the finish required. State the quantity you need checked and the question the part must answer: fit, function or appearance. Uploaded files are used only for the quotation, and non-disclosure agreements are supported.

Quality checks

Parts are inspected with a coordinate measuring machine, a projector and height gauges, with quality control at each production stage, and a dimension report can be provided for a project on request.
